CS/SS Pipe Guide- Model - CT-PG
Precision-engineered guide for carbon steel and stainless steel risers.
Allows smooth axial movement while preventing lateral stress and misalignment.
The CT-PG Pipe Guide from Crest Technologies is a robust, high-performance solution engineered for managing the axial movement of carbon steel and stainless steel piping in vertical and horizontal riser systems. Designed to ensure controlled thermal expansion while preventing lateral displacement, the CT-PG model enhances piping system stability and longevity in high-rise, industrial, and commercial mechanical installations.
Constructed from powder-coated carbon steel, the guide features two heavy-duty split cylinders that securely clamp around the pipe. Internally, UHMW polymer slides provide low-friction axial movement, enabling smooth thermal expansion and contraction. The guide is anchored to the slab or structural steel using bolted flanges, and accommodates a wide range of pipe sizes and insulation thicknesses.
.
COPPER PIPE GUIDE -MODEL -CT-CP
Engineered for carbon steel and stainless steel piping systems.
Ensures smooth axial movement and precise vertical alignment across riser shafts.
Crest Technologies’ Copper Pipe Guide – Model CT-CP is engineered specifically for copper riser applications where thermal expansion control and electrical isolation are critical. Designed with precision-machined carbon steel components and integrated dielectric isolators, the CT-CP model prevents galvanic corrosion while allowing smooth axial movement.
Each guide includes UHMW or PTFE liners to reduce friction, protect pipe surfaces, and enable consistent expansion under temperature fluctuations. The housing is fabricated from powder-coated carbon steel, offering long-term durability and corrosion resistance in mechanical shafts, vertical risers, and plumbing systems.
The CT-CP guide is ideal for HVAC, potable water, and domestic hot water lines using copper pipe systems in residential and commercial buildings
Suite Riser Guide - Model CT-RISER
The CT-RISER Suite Riser Guide by Crest Technologies is purpose-built for modern high-rise plumbing and HVAC systems, where vertical riser installation space is at a premium. Designed specifically for fan coil units and heat pump risers, this guide offers reliable support and movement control in tight mechanical shafts and rectangular floor penetrations.
Its low-profile, slab-mounted construction allows for seamless integration into multi-story residential and commercial buildings — delivering a clean, flush finish without compromising on functionality or performance.
Engineered using 3mm carbon steel, UHMW liners, and chrome-plated set screws, the CT-RISER ensures smooth axial pipe movement, excellent vibration control, and minimal thermal friction — even in highly compact vertical runs with insulation clearance concerns
Suite Riser Guide - Model CT-RISER
The CT-SPIDER is designed to guide insulated vertical riser pipes while allowing controlled movement during thermal expansion and contraction. Ideal for multi-storey mechanical systems, this guide maintains precise pipe alignment without supporting load weight, making it an essential component for stress-free pipe travel in riser shafts.
​
The CT-SPIDER is designed to guide insulated vertical riser pipes while allowing controlled movement during thermal expansion and contraction. Ideal for multi-storey mechanical systems, this guide maintains precise pipe alignment without supporting load weight, making it an essential component for stress-free pipe travel in riser shafts. Crafted with a wide anchoring base, slotted bolt holes, and high-grade UHMW inserts, the CT-SPIDER enables installers to position it with accuracy, lock it in place, and trust its stability even under constant system cycling. It’s available in multiple sizes, supporting insulation thicknesses up to 4 inches or more, with custom diameters on request — making it a go-to solution for complex vertical mechanical designs.
